Cement and acyrlic based, very elastic,two componential a waterproofing material.Two component each other should be mixed to provide insulation.Positive water pressure.
Interior and exterior,horizontal and vertical applications.Water tanks,cisterns,swimming pools ( with a condition covered over).Basic insulation,retaining walls and basement insulation.Purpose of permeability against salty waters .The insulation of terrace roofs.Sewer pipes.Irrigation canals,sewerage wells,concrete pipes.On wet areas such as bath,kitchen,balcony. Such as spa and bath facilities.Flower insulation. For bonding coating materials ceramic and granite .
İt is applied easy with brush,roller,trowel or sprayer on horizontal and vertical surfaces, it is not affected from cold and hot air. Provides a waterproof seamless and jointless.Provides high-performance waterproofing.Elastic,nonshrinking and not crack. Although not permeability of the water ,it provides concrete to breath .Nontoxic ,it is ideal for water tanks.Due to the property of high adhesion and flexibility, it creates excellent insulation layer under ceramic .Protects the concrete surfaces from carbonization and chloride.
It must be ensured that the application surface cured. The application surface should be cleaned from dust, oil, paint ,silicone ,curing agent and detergent such the materials which prevent adhesion.Should be repaired weak parts of concrete ,removed not good plasters,turned the surface solid and smooth ,repaired static cracks in the building with ALFILL LATEXFIL plaster or ALFILL UNIVERSAL GROUT High Strength Shrinkage Repair and Anchoring Mortar.Dynamic (moving) cracks should be repaired with polyurethane sealant.if it is existent ,irons and wedges on the surface should be removed and the holes which coming water, should be filled such as the productions WATERSTOP. The application surface should be water-saturated and during the application it is provided to remain moist.
7 kg. B Component put a clear plastic rough. Slowly 20kg. Component A added to liquid and externally without extra water,preferably mixed with the low speed mixer until homogenous. After 3-5 resting time , mixed more 30 second then started to apply. In pot the mix should be consumed within 30 minutes and if this time is exceeded , the mortar should not be used.
ALFILL ALFIZOL Two Componential Waterproofing Material is applied at least two layers being perpendicular to each other on the surface. After first coat application at +20°C’ at least 5-6 hours , this time should not exceed 24 hours. Second coat should be applied before first coat does not fully dry.If the first coat dried , the surface should be moistened before second coat not applied.
After second coat application , the surface should be kept against sun and fast dry during 3 days. During application after first coat application,corners should be beveled and then second coat should be applied on the bevel. During application it is suggested to used file between two coats. After 3 days mechanical strength gains , after 7 days becomes watertight.After 14 days the last strength gains.it should be not applied open terraces and balconies in windy weather ,rain and extreme hot weather.
On each coat 1 kg/m2 is applied and 1 mm. Thick obtained. 2 coat is suggested to applied (2 kg/m2). On high-level protection consumption quantity can be increased untill 3 - 4 kg/m2’.
Avoid to apply in the temperatures under +5°C and above +35°C. Avoid application frozen ,the risk of freezing within 24 hours or direct sun and wind in open areas .Don’t add externally water to the mix. Everytime powder component ,should be added to liquid component.During the application,wet film thickness of 2 mm should not exceed for a single layer.
Component A : 20 kg. kraft bags . Component B : 7 kg plastic drums. At humid conditions with 10-fold stacked on a pallet can be stored for 12 months. Shake liquid component Before use and protect against frost.
Health and Safety :
As all chemical products, during storage and handling it should be kept food products , the skin, eyes and mouth If swallowed accidentally, consult a doctor .In contact with skin , wash with plenty of water. Stored away from children.
|
Appearance |
A Component / Grey colored thin powder |
| B Component / White colored liquid | |
|
Density |
A Component / 1,40 kg/lt |
| B Component / 1,03 kg/lt | |
| Mixing Rate | 7 kg. liquid / 20 kg. powder |
| Application Temperature | +5°C with 35°C between |
| Flexibility |
Well |
| Pressured Water Resistance (DIN 1048) | 7 bar pozitive |
| Capillary Water Absorption (TS 4045) | 0,018 kg/m2h1/2 |
| Resting Time |
3-5 minute |
| Ready for Use | Mechanical Strength : 3 days |
| Water Tightness : 7 days | |
| Over Coating Time |
3 days |
| Service Temperature | -30°C / +80°C |
Cement-based,high performance, single component, easy processed,forming a smooth surface,flexible joint filler which used 1-6 mm joints.
İnterior and exteriors. Pool, water tank,bath and sauna etc spaces. Floor heating systems. Used to fill joints untill 1-6 mm of the coatings such as granite tiles,large-sized ceramic, tiles,natural granite,marble,clinker and glass mosaic.
Not being color fading,dusting and cracking.Provide a smooth surface. It is not affected by sudden temperature changes. Water and frost resistant.Has 34 different colors.
During the application of ceramics Be careful they well are adhering not to prolapse and so that completely dry With a thin rod or roller in joints spaces any dust ,dirt,wood chips,construction and cement residues should be cleaned well on completed floor surfaces.The cleaned spaces should be moistened with the helping a wet sponge
20 kg. “ALFILL FLEX FUGAFIL Joint Filler Material(1-6 mm)” joining into approximately 6,5 - 8 lt clear water, preferably mixed with the low speed mixer or trowel until homogenous. Be careful the water quantity which add to powder mortar, avoid to the application which participated more water in the form of sherbet. The water which included more than necessary will lead to cracking,easy detrital and dusting. The prepared thick emulsion joint sealant is rest nearly 5-10 minutes and re-mixing then used. In pot the mix should be consumed within nearly 1 hour.
Joint Filler should be filled with a hard rubber-based joint spread trowel or hard-rubber-tipped squeegee to joints. To filled well joints ,should be drawn firstly parallel and then diagonally.Being shaved excess mortar on the surface with moistened soft-tipped spatula, according to ambient temperature should be waited 15-30 minutes then wiping with a damp sponge then should be cleaned well thin joint layer on the surface . it dries on walls after 12 hours , can be walked after 24 hours on floors,can be opened to pedestrian traffic after 7 days .
See the statement of the joint sealant consumption.
Avoid to apply in the temperatures under +5°C and above +35°C. Avoid application frozen ,the risk of freezing within 24 hours or direct sun and wind in open areas . Don’t addition definitely dust and water to the mortar which has expired. Don’t clean with hydrochloric acid ,bleach etc. When used for underfloor heating systems,the surface should not be hot during the application, The heating system should be closed ago 24 hours.
1 kg, 4 kg, 10 kg and 20 kg kraft bags.in 20 kg packaging, Humid conditions and in unopened package with 10-fold stacked on a pallet can be stored for 12 months.
As all chemical products, during storage and handling it should be kept food products , the skin, eyes and mouth If swallowed accidentally , consult a doctor .In contact with skin , wash with plenty of water. Keep out of reach of children.
| Appearance | White or colored thin powder |
| Powder Density | 1,10 kg/lt. |
| Water Mixing Rate | 6,5-8 lt. water / 20 kg. powder |
| Resting Time |
5-10 Minutes |
|
Pot Life |
Approximately 1 hour |
| Application Temperature | +5°C with 35°C between |
| Ready for Use | On wall after 12 hours, on floor after 24 hours |
|
Flexibility |
Fine |
| Flexural Strength | > 3,5 N/mm2 (EN 12808-3) |
| Compressive Strength | > 15 N/mm2 (EN 12808-3) |
| Abrasion Resistance | > 1000 mm3 (EN 12808-2) |
|
Shrinkage |
> 2 mm/m. (EN 12808-4) |
| Water Absorption | ın 30 minutes <2 gr. (EN 12808-5) |
| In 240 minutes <5 gr. (EN 12808-5) | |
| Service Temperature | -30°C / +80°C |
Ceramic ,tile ,glass mosaic etc coating materials , indoors especially bath,kitchen like wet areas to wall and floor ,Is used laying the ground at outdoors .
Easy apply , robust and secure adhesion with polymer additives . Processing time is long , saving from time and labour. Provides the opportunity for a long time to correct pasted plates . On wet areas using safer .Water and frost resistant. Provides high stability , does not sag at vertical applications . From top-down floor provides .
It must be ensured that the application surface cured. should be cleaned from dust, oil, paint ,silicone ,curing agent and detergent such as anti-stick materials.it is necessary to wet and provided to remain moist . If the surface is too water-absorbent , it should be applied after taking a primer.
25 kg '' ALFILL LUX FILSER Ceramic Tile Adhesive ‘’ joining into approximately 6-7,5 lt clear water, preferably mixed with the low speed mixer or trowel until homogenous. The prepared mortar is rest of 5-10 minutes for the maturation and re-mixing and used. In pot the mix should be consumed within 2,5 – 3,5 hours.
At firstly , pressed adhesive mortar strongly on the application surface , create contact layer and then selected the appropriate size of tile with a notched trowel product dredged . Adhesive mortar should be provided to contact at least 80 % backside of the ceramic . According to used floor plates and the smoothness of the ground if necessary , be preferred ‘’ Double Sided Adhesive Method ‘’ , should be lead both backside of ceramic and on the ground and should be determine the plates , being perpendicular carding direction to each other . To provide good adhesion , with the help of a rubber hammer applying force , you should bond .To provide stronger adhesion at outdoor applications mixing with LATEXFIL or ALFIZOL B Component you apply
3,5 - 4 kg/m²
Avoid to apply in the temperatures under +5°C and above +35°C . Avoid application frozen ,the risk of freezing within 24 hours or direct sun and wind in open areas. Don’t addition definitely dust and water to the mortar which has expired .
25 kg kraft bag. Humid conditions and in unopened package with 10-fold stacked on a pallet can be stored for 12 months.
As all chemical products, during storage and handling food products should be kept the skin, eyes and mouth . If swallowed accidentally , consult a doctor .In contact with skin , wash with plenty of water
TS EN 12004 certified C1TE class
C: Cement based
1: Normal hardening (Standard performance )
T: Thixothropic
E : Extended working time
| Appearance | White or Grey colored thin powder |
| Powder Density | 1,45 kg/lt |
| Water Mixing Rate | 6-7,5 lt water / 25 kg powder |
| Resting Time | 5-10 minutes |
| Pot Life | Approximately 2,5 – 3,5 hours |
| Open Time Tensile Adhesion | After min. 30 mn.≥ 0,5 N/ mm² (EN 1346) |
| Application Temperature | +5°C with +35°C between |
|
Adhesion |
≥ 0,5 N/mm² (28 days) (EN 1348) |
|
Sliding |
≤ 0,5 mm (EN 1308) |
| Walking Over Time | 24 hours |
| Service Temperature | - 30°C / + 60°C |
Cement-based , single component , polymer and fiber-reinforced thin or thick aggregate surface repair and recension mortar .
İnterior and exterior. Restorations,repair of concrete and prefabricated concrete elements. Wall and ceiling plaster smoothing and repair. Prior to paint ,ceramic coating and insulation,is used to have a smooth and firm surface . ALFIL TAMIRFIL Repair Mortar (thin) until 5 mm is suitable for static (stationary )cracks . ALFIL TAMIRFIL Repair Mortar (thick) untill 30mm is suitable for static (stationary) cracks .
Cracking and dust does not. Easy apply. Dry quickly ,it allows use in a short time.Provide high adhesion uncoated.Water and frost resistant. Provide smooth finish on concrete surfaces. Optionally it produced thin and thick aggregate.
It must be ensured that the application surface cured. . should be cleaned from dust, oil, paint ,silicone ,curing agent and detergent such as materials which prevent adhesion.it is necessary to wet and provided to remain moist.
25 kg. ''ALFILL TAMIRFIL Repair Mortar '' joining into approximately 5-6 lt (thick nearly 4,5-5 lt) clear water, preferably mixed with the low speed mixer or trowel until homogenous. The prepared mortar is rest of 5-10 minutes for the maturation and re-mixing and used. In pot the mix should be consumed within 30 minutes.
Repair Mortar applied with the helping a trowel to torn,cracked,broken areas on the surface . “ALFILL TAMIRFIL Repair Mortar’’ Thin can be applied between 1-5 mm thick . “ALFILL TAMIRFIL Repair Mortar ‘’thick can be applied between 5-30 mm thick. After Application The surface is suggested to moistened at regular intervals within 24 hours.
Thin : 1,5 kg/m² ( For 1 mm. Thick ) / Thick : 2 kg/m2 ( For 1mm. Thick )
Avoid to apply in the temperatures under +5°C and above +35°C. Avoid application frozen ,the risk of freezing within 24 hours or direct sun and wind in open areas .Don’t addition definitely dust and water to the mortar which has expired.After application untill the mortar cured the surface should be remain moist.ıt does not applied on ready colored plasters,paints and exterior wall coverings.
25 kg. Kraft bags.
Humid conditions and in unopened package with 10-fold stacked on a pallet can be stored for 12 months.
As all chemical products, during storage and handling it should be kept food products , the skin, eyes and mouth If swallowed accidentally , consult a doctor .In contact with skin , wash with plenty of water.
| Appearance | Grey colored thin powder | Grey colored thick powder |
|
Powder Density |
1,45 kg/lt. | 1,60 kg/lt. |
| Water Mixing Rate | 5-6 lt. water / 25 kg. powder | 4,5-5 lt. water / 25 kg. powder |
| Resting Time | 5-10 minutes | 5-10 minutes |
| Pot Life | Approximately 30 minutes | Approximately 30 minutes |
| Application Temperature | +5°C with 35°C between | +5°C with 35°C between |
| Adhesion | > 0,5 N/mm² | > 0,5 N/mm² |
| Flexural Strength | > 3 N/mm² | > 4 N/mm² |
| Compressive Strength | > 10 N/mm² | > 15 N/mm² |
| Service Temperature | -20°C / +70°C | -30°C / +80°C |
Cement-based, single component, is powder mortar which used for bond tile and ceramic .
Indoors, horizontal and vertical surfaces , used bonding of small and medium sized floor and wall tiles over 3% water absorption rate . For maximum 33x33cm . size coating materials used .
Easy to apply , economic , does not sag at vertical applications.
It must be ensured that the application surface cured. should be cleaned from dust, oil, paint ,silicone ,curing agent and detergent such as anti-stick materials. it is necessary to wet and provided to remain moist. If the surface is too water-absorbent , it should be applied after taking a primer.
25 kg ''ALFILL TEKNOFIX Tile and Ceramic Tile Adhesive ‘’ joining into approximately 6-7 lt clear water, preferably mixed with the low speed mixer or trowel until homogenous. The prepared mortar is rest of 5-10 minutes for the maturation and re-mixing and used. In pot the mix should be consumed within 2 – 2,5 hours.
At firstly , pressed adhesive mortar strongly on the application surface , create contact layer and then selected the appropriate size of tile with a notched trowel the product dredged . Adhesive mortar should be provided to contact at least 80 % backside of the ceramic. To provide good adhesion , with the help of a rubber hammer applying force , you should bond.
3,5 - 4 kg/m²
Avoid to apply in the temperatures under +5°C and above +35°C. Avoid application frozen ,the risk of freezing within 24 hours or direct sun and wind in open areas .Don’t addition definitely powder and water to the mortar which has expired .
25 kg kraft bag. Humid conditions and in unopened package with 10-fold stacked on a pallet can be stored for 12 months.
As all chemical products, during storage and handling it should be kept food products , the skin, eyes and mouth If swallowed accidentally , consult a doctor .In contact with skin , wash with plenty of water.
| Appearance | Grey colored thin powder |
| Powder Density | 1,45 kg/lt |
| Water Mixing Rate | 6-7 lt water / 25 kg powder |
| Resting Time | 5-10 minutes |
| Pot Life | Approximately 2 – 2,5 hours |
| Open Time Tensile Adhesion | After min. 20 minutes≥ 0.5 N/mm² (EN 1346) |
| Application Temperature | +5°C with +35°C between |
|
Adhesion |
≥ 0,5 N/mm² (28 days) (EN 1348) |
|
Sliding |
≤ 0,5 mm (EN 1308) |
| Walking Over Time | 24 hours |
| Service Temperature | -20°C / +70°C |
İndoors and outdoors , horizontal and vertical surfaces , large-sized floor and wall tiles , granite, granite ceramic ,marble , clinker , furnishing of all kinds stone pavement , businesses are exposed to heavy pedestrian traffic,shopping centers,schools and hospitals like these spaces . Floor heating systems , Ceramic coating on the old granite and marble surfaces. Mosaic glass used for bond ing.
Flexible and strong adhesion. Water and frost resistant.Not affected by temperature changes. High stability , does not sag at vertical applications. From top-down floor provides.
It must be ensured that the application surface cured. should be cleaned from dust, oil, paint ,silicone ,curing agent and detergent such as anti-stick materials.it is necessary to wet and provided to remain moist . If the surface is too water-absorbent , it should be applied after taking a primer.
25 kg '' ALFILL SUPERFIX Granite Ceramic Tile Adhesive ‘’ joining into approximately 6-7 lt clear water, preferably mixed with the low speed mixer or trowel until homogenous. The prepared mortar is rest of 5-10 minutes for the maturation and re-mixing and used. In pot the mix should be consumed within 2 – 2,5 hours.
At firstly , pressed adhesive mortar strongly on the application surface , create contact layer and then selected the appropriate size of tile with a notched trowel the product dredged . Adhesive mortar should be provided to contact at least 80 % backside of the ceramic . According to used floor plates and the smoothness of the ground if necessary , be preferred ‘’ Double Sided Adhesive Method ‘’ , should be lead both backside of ceramic and on the ground and should be determine the plates , being perpendicular carding direction to each other . To provide good adhesion , with the help of a rubber hammer applying force , you should bond.
4 - 6 kg/m²
Avoid to apply in the temperatures under +5°C and above +35°C. Be careful the amount of the water involved to the mortar.Don’t add more water than necessary. Avoid application frozen ,the risk of freezing within 24 hours or direct sun and wind in open areas . Don’t addition definitely dust and water to the mortar which has expired .
25 kg kraft bag. Humid conditions and in unopened package with 10-fold stacked on a pallet can be stored for 6 months.
As all chemical products, during storage and handling it should be kept food products , the skin, eyes and mouth If swallowed accidentally , consult a doctor .In contact with skin , wash with plenty of water.
TS EN 12004 certified C2TE class
C: Cement based
2: High Performance
T: Thixothropic
E : Extended working time
| Appearance | White or Grey colored toz |
| Powder Density | 1,45 kg/lt |
| Water Mixing Rate | 6-7 lt water / 25 kg powder |
| Resting Time | 5-10 minutes |
| Pot Life |
Approximately 2 – 2,5 hours |
| Open Time Tensile Adhesion | After Min. 25 minute ≥ 0,5N/mm² (EN 1346) |
| Application Temperature | +5°C with +35°C between |
| Adhesion | ≥ 1,0 N/mm² (28 days) (EN 1348) |
| Sliding | ≤ 0,5 mm. (EN 1308) |
| Walking Over Time | 24 hours |
| Service Temperature | -30°C / +80°C |
Cement-based , single component , polymer and fiber-reinforced thin or thick aggregate surface repair and recension mortar .
İnterior and exterior. Restorations,repair of concrete and prefabricated concrete elements. Wall and ceiling plaster smoothing and repair. Prior to paint ,ceramic coating and insulation,is used to have a smooth and firm surface . ALFIL TAMIRFIL Repair Mortar (thin) until 5 mm is suitable for static (stationary )cracks . ALFIL TAMIRFIL Repair Mortar (thick) untill 30mm is suitable for static (stationary) cracks .
Cracking and dust does not. Easy apply. Dry quickly ,it allows use in a short time.Provide high adhesion uncoated.Water and frost resistant. Provide smooth finish on concrete surfaces. Optionally it produced thin and thick aggregate.
It must be ensured that the application surface cured. . should be cleaned from dust, oil, paint ,silicone ,curing agent and detergent such as materials which prevent adhesion.it is necessary to wet and provided to remain moist.
25 kg. ''ALFILL TAMIRFIL Repair Mortar '' joining into approximately 5-6 lt (thick nearly 4,5-5 lt) clear water, preferably mixed with the low speed mixer or trowel until homogenous. The prepared mortar is rest of 5-10 minutes for the maturation and re-mixing and used. In pot the mix should be consumed within 30 minutes.
Repair Mortar applied with the helping a trowel to torn,cracked,broken areas on the surface . “ALFILL TAMIRFIL Repair Mortar’’ Thin can be applied between 1-5 mm thick . “ALFILL TAMIRFIL Repair Mortar ‘’thick can be applied between 5-30 mm thick. After Application The surface is suggested to moistened at regular intervals within 24 hours.
Thin : 1,5 kg/m² ( For 1 mm. Thick ) / Thick : 2 kg/m2 ( For 1mm. Thick )
Avoid to apply in the temperatures under +5°C and above +35°C. Avoid application frozen ,the risk of freezing within 24 hours or direct sun and wind in open areas .Don’t addition definitely dust and water to the mortar which has expired.After application untill the mortar cured the surface should be remain moist.ıt does not applied on ready colored plasters,paints and exterior wall coverings.
25 kg. Kraft bags.
Humid conditions and in unopened package with 10-fold stacked on a pallet can be stored for 12 months.
As all chemical products, during storage and handling it should be kept food products , the skin, eyes and mouth If swallowed accidentally , consult a doctor .In contact with skin , wash with plenty of water.
| Appearance | Grey colored thin powder | Grey colored thick powder |
|
Powder Density |
1,45 kg/lt. | 1,60 kg/lt. |
| Water Mixing Rate | 5-6 lt. water / 25 kg. powder | 4,5-5 lt. water / 25 kg. powder |
| Resting Time | 5-10 minutes | 5-10 minutes |
| Pot Life | Approximately 30 minutes | Approximately 30 minutes |
| Application Temperature | +5°C with 35°C between | +5°C with 35°C between |
| Adhesion | > 0,5 N/mm² | > 0,5 N/mm² |
| Flexural Strength | > 3 N/mm² | > 4 N/mm² |
| Compressive Strength | > 10 N/mm² | > 15 N/mm² |
| Service Temperature | -20°C / +70°C | -30°C / +80°C |
| Bucket | ||
| G. Dump Clearance at Max Raise | 9.5 ft in | 2890 mm |
|
Dimensions |
||
| A. Length with Bucket on Ground | 26.3 ft in | 8025 mm |
| B. Width Over Tires | 9.5 ft in | 2890 mm |
| C. Height to Top of Cab | 11.5 ft in | 3500 mm |
| E. Ground Clearance | 1.3 ft in | 400 mm |
| H. Reach at Max Lift and Dump | 4.2 ft in | 1270 mm |
|
Dimensions |
||
| A. LENGTH W/ BLADE | 19.1 ft in | 5817 mm |
| B. WIDTH OVER TRACKS | 9.4 ft in | 2869 mm |
| C. HEIGHT TO TOP OF CAB | 11.7 ft in | 3573 mm |
| D. LENGTH OF TRACK ON GROUND | 9.4 ft in | 2878 mm |
| E. GROUND CLEARANCE | 1.4 ft in | 414 mm |
| F. LENGTH W/O BLADE | 15.5 ft in | 4736 mm |
|
Undercarriage |
||
| G. TRACK GAUGE | 6.5 ft in | 1981 mm |
| H. STANDARD SHOE SIZE | 22 in | 560 mm |
1300 in stock
Shop from a Wide Variety of Building Materials and Construction Equipment like Concrete, Cement & Masonry, Mortar, Cement and Concrete Mixers, Concrete Blocks and Bricks, Concrete Sealers & Repair, Hardware, Sanitary Ware, Tiles, Plumbing Equipment, Bathroom Accessories, Showroom, Graders, Pavers, Sinks, Toilets, Wash Hand Basins, Bathroom Cabinets, in Kampala Uganda, Nairobi Kenya, Kigali Rwanda, East Africa, South Sudan, Tanzania, Burundi, DR Congo. Browse the collections right now.
Counter Top & Wash Hand Basins
|
Dimensions |
||
| A. Length w/ Blade | 18.2 ft in | 5559 mm |
| B. Width Over Tracks | ft in | mm |
| C. Height to Top of Cab | 10.9 ft in | 3336 mm |
| D. Length of Track on Ground | 9.5 ft in | 2896 mm |
| E. Ground Clearance | 1.3 ft in | 403.5 mm |
| F. Length w/o Blade | 15.2 ft in | 4619 mm |
|
Undercarriage |
||
| G. Track Gauge | 6.5 ft in | 1981 mm |
| H. Standard Shoe Size | 20.1 in | 510 mm |
1300 in stock
|
Bucket |
||
| G. Dump Clearance at Max Raise | 8.8 ft in | 2659 mm |
|
Dimensions |
||
| A. Length with Bucket on Ground | 20.4 ft in | 6229 mm |
| B. Width Over Tires | 7.9 ft in | 2434 mm |
| C. Height to Top of Cab | 10.2 ft in | 3100 mm |
| D. Wheelbase | 8.5 ft in | 2600 mm |
| E. Ground Clearance | 1.5 ft in | 456 mm |
| F. Hinge Pin - Max Height | 11.3 ft in | 3435 mm |
| H. Reach at Max Lift and Dump | 3.2 ft in | 973 mm |
| Dimensions | ||
| A. LENGTH W/ BLADE | 18.2 ft in | 5559 mm |
| B. WIDTH OVER TRACKS | ft in | mm |
| C. HEIGHT TO TOP OF CAB | 10.9 ft in | 3336 mm |
| D. LENGTH OF TRACK ON GROUND | 9.5 ft in | 2896 mm |
| E. GROUND CLEARANCE | 1.3 ft in | 403.5 mm |
| F. LENGTH W/O BLADE | 15.2 ft in | 4619 mm |
|
Undercarriage |
||
| G. TRACK GAUGE | 6.5 ft in | 1981 mm |
| H. STANDARD SHOE SIZE | 20.1 in | 510 mm |
| Model | Voltage (V) | Power (kW) | Current (A) | Dimensions (mm) | Weight (kg) | ||||||||
| DN1 | DN2 | L | H | H1 | W | A | B | C | |||||
| CPm 158 | 1x240 | 0.75 | 5.8 | 1” | 1” | 285 | 240 | 92 | 190 | 540 | 225 | 585 | 19.9 |
|
Boom/Stick Option
|
||
| A. Shipping Length of Unit | 29.1 ft in | 8870 mm |
| C. Shipping Height of Unit | 10.1 ft in | 3080 mm |
| I. Max Cutting Height | 29.3 ft in | 8920 mm |
| J. Max Loading Height | 20.3 ft in | 6160 mm |
| K. Max Reach Along Ground | 28.4 ft in | 8650 mm |
| L. Max Vertical Wall Digging Depth | 15.8 ft in | 4830 mm |
| M. Max Digging Depth | 19.4 ft in | 5920 mm |
|
Dimensions |
||
| B. Width to Outside of Tracks | 9.2 ft in | 2800 mm |
| D. Length of Track on Ground | 11.3 ft in | 3450 mm |
| E. Ground Clearance | 1.5 ft in | 460 mm |
| G. Height to Top of Cab | 10.1 ft in | 3080 mm |
| H. Tail Swing Radius | 8.3 ft in | 2540 mm |
|
Undercarriage |
||
| F. Track Gauge | 7.8 ft in | 2200 mm |
| N. Shoe Size | 24 in | 600 mm |
|
Boom/Stick Option
|
||
| A. Shipping Length of Unit | 32.9 ft in | 10042 mm |
| C. Shipping Height of Unit | 9.9 ft in | 3011 mm |
| I. Max Cutting Height | 35.6 ft in | 10850 mm |
| J. Max Loading Height | 25.2 ft in | 7690 mm |
| K. Max Reach Along Ground | 30.7 ft in | 9350 mm |
| L. Max Vertical Wall Digging Depth | 10.8 ft in | 3280 mm |
| M. Max Digging Depth | 13.6 ft in | 4160 mm |
|
Dimensions |
||
| B. Width to Outside of Tracks | 9.8 ft in | 2980 mm |
| D. Length of Track on Ground | 12 ft in | 3650 mm |
| E. Ground Clearance | 1.5 ft in | 460 mm |
| G. Height to Top of Cab | 9.7 ft in | 2950 mm |
| H. Tail Swing Radius | 9.1 ft in | 2770 mm |
|
Undercarriage |
||
| F. Track Gauge | 7.8 ft in | 2380 mm |
| N. Shoe Size | 23.6 in | 600 mm |
|
Boom/Stick Option
|
||
| A. Shipping Length of Unit | 31 ft in | 9440 mm |
| C. Shipping Height of Unit | 12.3 ft in | 3740 mm |
| I. Max Cutting Height | 32.6 ft in | 9940 mm |
| J. Max Loading Height | 22.8 ft in | 6940 mm |
| K. Max Reach Along Ground | 35.3 ft in | 10760 mm |
| L. Max Vertical Wall Digging Depth | 22.8 ft in | 6970 mm |
| M. Max Digging Depth | 25.2 ft in | 7660 mm |
|
Dimensions |
||
| B. Width to Outside of Tracks | 9.9 ft in | 3017.5 mm |
| D. Length of Track on Ground | 10.8 ft in | 3265 mm |
| E. Ground Clearance | 1.5 ft in | 450 mm |
| G. Height to Top of Cab | 9.7 ft in | 2950 mm |
| H. Tail Swing Radius | 9 ft in | 2750 mm |
| O. Counterweight Clearance | 3.3 ft in | 1020 mm |
|
Undercarriage |
||
| F. Track Gauge | 7.3 ft in | 2200 mm |
| N. Shoe Size | 24 in | 600 mm |
|
Bucket |
||
| G. Dump Clearance at Max Raise | 9.4 ft in | 2879 mm |
|
Dimensions |
||
| A. Length with Bucket on Ground | 23.8 ft in | 7252 mm |
| B. Width Over Tires | 8.4 ft in | 2570 mm |
| C. Height to Top of Cab | 10.7 ft in | 3269 mm |
| D. Wheelbase | 9.5 ft in | 2900 mm |
| E. Ground Clearance | 1.3 ft in | 408 mm |
| F. Hinge Pin - Max Height | 12.7 ft in | 3872 mm |
| H. Reach at Max Lift and Dump | 3 ft in | 927 mm |
2 BHK & 1 BHK - Apartments Plan
Waterproofing Material - ALFIZOL
FLEX FUGAFIL Joint Filler Grout
LUX FILSER - Ceramic Tile Adhesive
TEKNOFIX Ceramic Tile Adhesive
Browse the collection of our best selling and top interesting products.
You’ll definitely find what you are looking for.
Artistic Renovations provide our homeowners with the highest quality craftsmanship for additions, historical renovations, kitchen design, bathroom design, interior renovations, exterior renovations, complete whole house renovations and even help homeowners that are looking for a home.
The cornerstone of the company is being a “clients dream”, a one stop shop for all your construction needs. Our mission is to be the preeminent concrete construction company through continuous improvement and our commitment
Format Homes is a multi-award winning home builder, known for building some of the best homes in South Australia.
Lash Urban Construction Ltd moved to 6th Street, Industrial Area, Kampala. The New home houses Office Partitions, Showrooms and Warehouses for all the construction Materials
The company offers design and installation of aesthetic environments. Using knowledge and expertise, Motion Gardeners evaluate every property, discuss the clients preferred design ideas and provide schematics for one to visualize their desired premises before ground breaking. In addition to the above, Motion Gardeners offers clean ups and ground maintenance services.
Orbit Homes is a family owned and operated home builder for more than 35 years, Specialising in brand new single and double storey homes.
Sprouting seeds is an annex of Elevate dealing in ornamental trees, shrubs, flowers and grass. Our well stocked nursery with over 25 different species of trees, shrubs and flowers located off salama road munyonyo, is one stop shop for all your gardening/garden beautification needs.
View the products listing via https://kumukutu.com/index.php/vendor/wayo-limited/
KumuKutu brings you all the Construction & Building Materials Manufacturers and Vendor into one virtual Market space where Buyers can make direct orders and Payments. Get all Roofing, Sanitary Ware, Plumbing and Waterproofing, Paint, Bath Tubs & Bathroom Accessories, Trucks, Tiles, Water Tanks, Heaters & Pumps, Mirrors.
